| Focal Length |
8mm |
| Max. Aperture Ratio |
1:2.8 |
| Max. Image Format |
14.2mm x 10.4mm (Φ17.6mm) |
| Operation Range |
Iris |
F2.8 - F16.0 |
| Focus |
0.2m - Inf. |
| Control |
Iris |
Manual |
| Focus |
Manual |
| Object Dimension at M.O.D |
375.6(H)mm x 273.3(V)mm 1.1" |
| Angle of View |
D |
1.1" |
93.9° |
1" |
89.3° |
2/3" |
69.0° |
| H |
83.0° |
77.3° |
57.3° |
| V |
66.0° |
61.7° |
44.2° |
| Operating Temperature |
-10° C ~ +50° C |
| Distortion |
1.1" |
-0.6%(y=8.8) |
1" |
-1.7%(y=8.0) |
2/3" |
-2.8%(y=5.5) |
| Back Focal Length |
8.6mm |
| Flange Back Length |
17.526mm |
| Mount |
C-Mount |
| Filter Size |
M72 P=0.75mm (with VM0811)* |
| M67 P=0.75mm (with VM0810)* |
| Weight |
155g |
| Dimensions |
Φ75mm x 54mm |
 |
| *There in no filter mount on the top of the lens. |
