F10819-01

F10819-01

產品型號：F10819-01
產品說明：

價格(NTD)：$0

產品規格

Model No	F10819-01
Fiber Type	Single-Mode
Operating Wavelength	1550 nm
Cutoff Wavelength	≤ 1500 nm
Mode Field Diameter	@ 1550 nm, 10.3 ± 0.4 µm
Attenuation	@ 1550 nm, ≤ 0.6 dB/km
Numerical Aperture (Nominal)	0.12
Core Diameter (Nominal)	9.3 µm
Clad Diameter	125 ± 2 µm
Coating/Buffer Diameter	245 ± 15 µm
Clad Non-Circularity	≤ 2.0%
Core/Clad Offset	≤ 1 µm
Coating Material	Dual UV Acrylate
Operating Temperature	-40 to +85℃
Short-Term Bend Radius	≥ 10 mm
Long-Term Bend Radius	≥ 17 mm
Proof Test Level	≥ 100 kpsi (0.689 Gpa)
