BF06160-02

BF06160-02

產品型號：BF06160-02
產品說明：

價格(NTD)：$0

產品規格

Model No	BF06160-02
Fiber Type	Single-Mode
Operating Wavelength	1550 nm
Cutoff Wavelength	≤ 1290 nm
Mode Field Diameter	@ 1310 nm, 5.1 ± 1.0 µm; @ 1550 nm, 5.8 ± 1.0 µm
Attenuation	@ 1310 nm, ≤ 1.2 dB/km; @ 1550 nm, ≤ 0.9 dB/km
Numerical Aperture (Nominal)	0.21
Core Diameter (Nominal)	4.6 µm
Clad Diameter	125 ± 2 µm
Coating/Buffer Diameter	155 ± 5 µm
Cladding Non-Circularity	≤ 2.0%
Core/Clad Offset	≤ 1 µm
Coating Material	PYROCOAT®
Operating Temperature	-65 to +300℃
Short-Term Bend Radius	≥ 10 mm
Long-Term Bend Radius	≥ 17 mm
Proof Test Level	≥ 100 kpsi (0.689 Gpa)
