| Model No |
UNI84611 |
| Operating Temperature (°C) |
-40 to 100 |
| Responsivity @ 970nm (A/W) |
Minimum: 0.6 Typical: 0.65 |
| Capacitance @ VR=-10V (pF) |
7.00 |
| NEP (W/ Hz½) |
9.9 x 10-15 @ -10 V, 970nm |
| Active Area (mm²) |
2.8 |
| Size of Active Area (mm) |
0.6 x 4.6 |
| Package |
41 / TO-5 |
| Dark Current @ Vʀ=-10V (nA) |
Maximum: 2 Typical: 0.13 |
| Element Gap (mm) |
0.025 |
| Maximum Reverse Voltage (V) |
30.00 |
| Rise Time (ns) |
4.00 |
| Storage Temperature (°C) |
-55 to 125 |
| RoHS |
Compliant |
