| Model No |
110-10083-0001 |
| Center Wavelength |
980 nm |
| Clear Aperture |
4 mm |
| Waveplate |
Yes |
| Spectral Range |
950 nm to 1010 nm |
| Isolation at 22 °C a |
>27 dB |
| Transmission at 22 °C b |
>88% |
| Polarizer Type |
PBS Cube |
| Pulsed Damage Threshold c |
1 J/cm² at 10 ns |
| Input Polarization |
Horizontal / Vertical / 45° (Polarization must be specified on order) |
| Output Polarization |
Horizontal / Vertical / 45° (Polarization must be specified on order) |
| Remark a |
When tuned for maximum isolation |
| Remark b |
At center wavelength |
| Remark c |
Isolators with PBS cube polarizers have CW damage threshold of 2 KW/cm2 |
| Note 1 |
The addition of a waveplate may restrict wavelength range. |
| Note 2 |
Product specifications are subject to change. All products are RoHS compliant. |
