UHL6388MG VIS Laser Diode

UHL6388MG

Model：UHL6388MG
Description：

Price(USD)：$0

Specification Content

Model No	UHL6388MG
Wavelength	637 nm
Output Power	250 mW
Operating Current	340 mA
Operating Voltage	2.3 V
Beam Divergence - Parallel	10°
Beam Divergence - Perpendicular	40°
Spatial Mode	Multimode
Package	Ø5.6 mm
PIN Code	H

The specifications provided on this page are for reference only. Actual product specifications are subject to the manufacturer’s latest official information.
