UHL63142DG VIS Laser Diode

UHL63142DG

Model：UHL63142DG
Description：

Price(USD)：$0

Specification Content

Model No	UHL63142DG
Wavelength	637 nm
Output Power	100 mW
Operating Current	140 mA
Operating Voltage	2.7 V
Beam Divergence - Parallel	8°
Beam Divergence - Perpendicular	18°
Spatial Mode	Single Mode
Package	Ø5.6 mm
PIN Code	A

The specifications provided on this page are for reference only. Actual product specifications are subject to the manufacturer’s latest official information.
