Model：UNI57513
Description：

Price(USD)：$0

Specification Content

Model No	UNI57513
Type	Biased
Voltage Bias, VBias(V)	-5
Note	Low Noise Response
Protective Window	Borosilicate
Operating Temperature (°C)	-20 to 75
Responsivity @ 900nm (A/W)	0.62
NEP (W/ Hz½)	8.6 x 10^-14
Detectivity (cmHz½/W)	1.2 x 10¹³ @ -5 V, 950nm
Shunt Resistance (MΩ)	30.00
Active Area (mm²)	100.0
Package	TO-5
Rise Time (ns)	200 @ 5 V/50 Ω, 670nm
Saturation Current, Isat (mA)	10.0
Terminal Capacitance (pF)	1700 @ 0 V; 500 @ 5 V
Typical Applications	Low light levels, long integration times
RoHS	Compliant

Unice Silicon Detector

Unice photodiodes
