Glass Sheet Polarizers
Glass Sheet Polarizers
Product name : Glass Sheet Polarizers
Description :
Glass sheet polarizers have unique qualities in terms of mechanical properties, resistance as well as optical performance. These elements can be used in a huge variety of applications, such as electro optics, interferometry, lasers, etc.
Features
● Extinction ratio >10000:1
● High transmittance
● Broad spectral bandwidth
● Wide acceptance angle
● Very thin
Specification
| Substratel Material | Soda-lime |
| Wavelength range | 600 – 2000 nm |
| Dimensions | from 5 to 100 mm |
| Shape | Round, Rectangular |
| Extinction ratio | >10000:1 (wavelength dependent) |
| Operating temperature | -50 to 400 °C |
| Surface Quality (S-D) | 80-50 |
| Coatings | Single layer MgF2 |
 |
|
| Model | Description | Wavelength (nm) | Dimensions (mm) | Price(USD) | Quantity | |
|---|---|---|---|---|---|---|
| 0 | ALT-POL-350-R | Glass Sheet Polarizer | 750 - 950 | 20.6 x 11 | - | |
| 1 | ALT-POL-95153-C750-950 | Glass Sheet Polarizer | 750 - 950 | 15.3 x 9.5 | - | |
| 2 | ALT-POL-508508-C750-950 | Glass Sheet Polarizer | 750 - 950 | 50.8 x 50.8 | - |
