OMF U-MF2 Fluorescence Filter Holder for Olympus Microscopes

OMF

Model：OMF
Description：

Price(USD)：$0

Content

General information

Specification	Value
Microscope Manufacturer	Olympus
Compatible Microscope(s)	AX Series - AX70 BX2 Series - BX41, BX50, BX51, BX60, BX61, BX50/51WI, BX60/61WI IX2 Series - IX50, IX51, IX70, IX71, IX81

Filter Size Information

Specification	Value
Exciter Diameter	25.0 mm
Exciter maximum thickness	5.0 mm
Emitter Diameter	25.0 mm
Emitter maximum thickness	5.0 mm
Beamsplitter Dimensions (L x W)	25.2 mm x 35.6 mm
Beamsplitter maximum thickness	1.5 mm
Note	This cube can be purchased individually or with filters. When ordering, specify "OMF" and if you would like complimentary filter mounting to be performed by our certified staff
