| Model No |
UNI62718 |
| Wavelength (nm) |
632.8 |
| Pointing Stability (mrad/°C) |
N/A |
| Pointing Stability after Warm Up (mrad/°C) |
N/A |
| Output Power (mW) |
1.5 |
| Beam Diameter (mm) |
0.63 |
| Beam Divergence (mrad) |
1.30 |
| Polarization |
Random |
| Static Alignment |
Centered to Outer Cylinder: ±0.01" Parallel to Outer Cylinder: ±1.0 mrad |
| Beam Diameter Tolerance (%) |
±3 |
| Beam Divergence Tolerance (%) |
±3 |
| Color |
Red |
| Diameter of Laser Head (inches) |
1.245 |
| Laser Class - CDRH |
IIIa |
| Length of Laser Head (inches) |
9.50 |
| Longitudinal Mode Spacing, Nominal (MHz) |
730 |
| Maximum Drift |
Mean Power over 8 hrs: ±2.5 |
| Minimum Output Power, TEM00 (mW) |
1.5 |
| Mode Purity (TEMoo) |
>95% |
| Operating Humidity |
0 to 100%, non-condensing |
| Operating Temperature (°C) |
-40 to +70 |
| Output Type |
Free Space |
| Power Supply |
UNI11387 110V or 220V, Switchable , ( Sold Separately ) |
| RMS Noise |
30 Hz - 10 MHz: 0.1% |
| Spatial Mode |
TEM00 |
| Storage Temperature (°C) |
-40 to +150 |
| Warm-Up Time (minutes) |
10 |
| Weight (lbs) |
0.54 |
| Reach 197 |
Compliant |
| RoHS |
Not Compliant |
